This page documents Quickcam (and similar video/web cameras) comments, tips, and photos. Also, see the Quickcam references on the Astrophotography - Basics page. Search the site for other items about webcams. Contributions welcome.
Subject: The Best ETX WEBCAM invention this year!!! Date: 3/22/04, 07:09 From: firstname.lastname@example.org Amazing! astrosurf.com/astrobond/ebrawf.htm of astrosurf.com/astrobond/ebrawe.htm (english version) Be sure to use the latest macro http://www.astrosurf.com/astrobond/BERaw.zip number 3: 3) 'Set OPTIMIZED COLOR (NON RAW) Mode AND Special Factory Settings' C'est la nouvelle macro NON RAW pour capteurs COULEUR mais avec le benefice des modifs RAW (moins de bruit, moins d'artefacts et plus de peche dans le sombre :o))) Ce mode ne necessite PAS DE DECODAGE, on travaille exactement comme avant au niveau des acquisitions et du traitement, la seule difference avec le vrai RAW Couleur se situant au niveau de la resolution qui n'est pas ameliorée dans ce cas... alors qu'en theorie, on peut gagner un peu en resolution en mode RAW Couleur :o) Good Luck Job Geheniau The NetherlandsAnd:
About the modification I just send you. There is a new macro for it so that you can use it without the raw frames with your color webcam. Problem is that you can only download the new macro on the FRENCH site under: http://astrosurf.com/astrobond/ebrawf.htm Dernieres Nouvelles du RAW... !!! (i.e. new update for raw), download the macro and choose number 3 3) 'Set OPTIMIZED COLOR (NON RAW) Mode AND Special Factory Settings' Job Geheniau The Netherlands
Subject: M42 photo Date: 3/20/04, 12:36 From: Franck Bouquerel Wanadoo (Franck.Bouquerel@Wanadoo.fr) Please find here for your website my first photo done with my ToUcam modified "SC". It's the central zone of M42 Done by Franck Bouquerel & Florence Clément Location : Côme Lake, Italia ETX125 with focal reduced 0.5 14 x 3s acquisition with AstroSnap pregistration with Registax Franck,
Subject: photos of Saturn and Jupiter Date: 3/17/04, 13:31 From: val-dick (email@example.com) Using the information in the great article on Registax in the April S&T, I finally have some photos of Jupiter and Saturn that I'm willing to send. Dick Kafka (Silver Spring, MD); MEADE ETX-125EC UHTC with 2x Barlow Lens and PHILIPS ToUcam PRO, camera in eyepiece holder; all captured with AVIedit, processed with Registax2D, ver 2.1. North up, as shown in latest Sky and Telescope (this is Y Flip from camera and Registax). 90% image qualityColor processing, wavelet filtering, 5% brightness reduction of blue and green for image of Jupiter. Saturn: 2/17/2004, 0057 UT (7:57 PM EST, 3/16); 5 fps, 1/25,(186 of 600 frames)
Jupiter: 3-14-2004 0137UT (9:37 PM EST, 3/13); 10 fps, 1/33 (344 out of 1199 frames); manually guided the image on the screen to stay away from bad spots on camera Autostar set to lowest slew rate; The shadow is of Ganymede.
Subject: Planet Photos Date: 3/14/04, 11:11 From: Chuck Falcone (firstname.lastname@example.org) Last night after several months I finally got a chance to look at the night sky. I decided to take a picture of Venus since it was in a good position to try. I heard it helps to use a lunar filter to cut down on the glare so I did. After taking the Venus picture I proceeded to take a picture of Jupiter. I was unaware that Ganymede and Io were transiting the planet. I forgot to take the lunar filter off when I took the Jupiter photo. No enhancements were made to either photo except Registax. The equipment used... ETX125EC and a Quickcam Pro 4000. Venus was taken at 5 frames per second for 1 minute, and Jupiter was 5 frames per second for 2 minutes. I'm not quite sure if the small dot in the middle of the upper cloud belt just left of the shadow is IO. If you have an opinion on this please let me know. Many Thanks! Chuck Falcone Lat 32° 46.8 Long 117° 4.2 email@example.com
Mike here: That sure looks like a moon shadow.
Subject: Wireless Video Cams Date: 3/9/04, 11:18 From: yagis (firstname.lastname@example.org) Are there any of you using spy cams via TV-Card to create AVI files. You can average 80ft distance remotely from comfort of home. The reason is that if you use such a system you can attach the camera to the eyepiece and recieve the images inside your shack while the scope remains outside tracking with autostar. This will do away with the need for USB relay`s which will cost about $140 for 80ft. Dont know if these 1.2Ghz devices are legal. I remember a case of a guy here in Limerick (15mls Shannon Airport) who got a visit from the heavies. It seems he was interfering with the local Airport Radar station. This case was taken to court. Anyway..Any info greatly accepted. Billy. Rep.Ireland.
Subject: Saturn image taken with a ETX-70 Date: 2/25/04, 10:28 From: Cairnsie13@aol.com Here is my second ever image of Saturn. It was taken using a Phillips Toucam 2 attached to a ETX-70 at prime focus with a 3x barlow. A 20 second AVI was recorded and then was processed using Registax. The picture was recorded on the 25th of february from Sunderland England. Thanks for providing such a great site. Chris Cairns
Subject: Etx125 images of Eskimo Nebular Date: 2/24/04, 13:33 From: Jan (email@example.com) This is my latest: NGC2392 "Eskimo Nebula" ETX125 ToUcam with 0.6 + 0.3 ext focal reducer. 41 out of 345 20sec images. Some curve, selective blur and color correction in photoshop. Hope you can place it on you deepsky gallery Jan the Netherlands members.home.nl/damhof/astro/
Subject: Saturn Pics Date: 2/24/04, 05:51 From: DAVID_MANN@SIMONSGROUP.COM Here's the pics of Saturn I took last night from Lincoln UK. By the time I had got around to taking them the sky had misted over a little. There are 2 Pics details as follows Satwebcam.jpg Telescope ETX-105EC Alt/Az easy aligned Logitech Quickcam Pro4000 Webcam with Lense removed at Prime Focus. 77 frames out of 254 stacked using Registax, Unsharp mask in Photoshop. Satcanon.jpg ETX-105EC Alt/Az easy aligned Meade 40mm Eypiece Canon Powershot S30 Manual Mode 10x Digital zoom 6 images of 1/5s each stacked and processed in Registax. Hope you'll put them on your guest astrophotography section of the website. Many thanks Dave
Subject: saturne Date: 2/17/04, 09:21 From: Yannick HOLMES (firstname.lastname@example.org) A picture of saturne, taken in Paris on the 16/02/2004 with an ETX 105 EC, Barlow 2x, ToUcam Pro. Add of 198 pictures from 1800/AVI. PRISM5 "wavelet" 0/5/5/1/1 on RVB pictures. And change the light and contrast. Thanks
Subject: Date: 2/17/04, 09:16 From: Yannick HOLMES (email@example.com) My firt shoot of Venus. Taken in Paris the 16/02/2004, with an ETX 105 EC, Barlow 2x and ToUcam Pro. / PRISM 5. (I have just changed the light and the color) Good reception
Mike here: PLEASE READ THE Email Etiquette ITEM! Your message was originally DELETED UNREAD as SPAM due to the missing Subject Line.
Subject: Webcam Modifications Date: 2/17/04, 01:46 From: kevin keyes (firstname.lastname@example.org) I just got done reading the latest updated posts to your site. I've seen posts like Stephan Loveday's concerning webcam modification for long exposures. I found this website that may be of help to webcam imagers. It is for the QuickCam and Unconventional Imaging Astronomy Group. They're address is www.qcuiag.co.uk. Are you familar with them? I didn't see they're url listed on the Astronomy links page. I personally have not modified my ToUcam Pro, since I only use it for planetary imaging. But from what I have read, they're information seems pretty solid. I hope this helps, Kevin Keyes
Subject: (sans sujet) Date: 2/16/04, 00:30 From: YannHolmes@aol.com Hello from Paris, Sorry for my english. Here's my first shoot of Jupiter. This picture has been taken on the 14/02/2004 from Paris, with an ETX 105 EC, Barlow 2X and ToUcam Pro. Add of 100 pictures from 1800. Prism 5 / "Masque flou" 6 and I have changed the light and contraste.
A shoot of Saturne. ETX 105 EC, Barlow 2X, and ToUcam Pro. Taken from Paris on the 14/02/2004. Add of 360 pictures from 1800. Prism 5 / "Wavelet 1/4/4/1/1" on RVB pictures. And "Masque flou" 3. Thanks a lot for your site.
Mike here: PLEASE read the Email Etiquette item on the ETX Site home page; your message was originally seen as SPAM and deleted UNREAD due to the missing subject entry.
Subject: Toucam Pro & Mac Date: 2/15/04, 16:09 From: Stephen Loveday (email@example.com) I'm trying to find out how to modify my Toucam Pro One for long exposure with my Mac computer. Do you have any ideas? Also I'm using Keith's image stacker, do you know of any other programs that work with a Mac for automatic stacking and aligning of images? Thanks SteveMike here: Sorry, no can help with that. You might sign up for the AstroMac mailing list; lots of good people there (link at the bottom of my ETX Site Home Page). And yes, Keith's Image Stacker is the only one currently although either Registax or Astrostack is supposed to come out with a Mac OS X version this year.
Subject: picture of Saturn Date: 2/14/04, 20:55 From: Dave Adriance (firstname.lastname@example.org) Attached is my latest picture of Saturn, taken on Valentine's Day (night...) in Nairobi, Kenya with the ETX-125, Meade 2X barlow and a ToUcam Pro webcam. 900 frames captured at 10 frames/second and 125 best stacked with K3CCD Tools. Unsharp masking and contrast adjustment with Photoshop. Thanks and regards, D.
Subject: Moon - Shiller Date: 2/10/04, 13:01 From: "C.Tex" (email@example.com) this is Shiller, a particular crater of Moon. It seems to come from the fusion of 2 craters or from a low-angled meteorite impact. In the future I'll try to take more details! Features: - Meade ETX 105 UHTC and Autostar; - Philips ToUcam Pro and Baader IR-Cut; - Barlow Televue 2X. The image has been processed with Registax. Best Regards Carlo
Subject: toucam pro 740k Date: 1/28/04, 09:00 From: Saverio Riboli (firstname.lastname@example.org) i have read in the site of qcuiag www.qcuiag.co.uk that is possible use webcams without modification for deep sky use. The site speak of astrovideo, a software that can sum a video sequence for create an effect similar at long exposure mode if webcam is suffly sensible.The webcam philips toucam pro are sensible for this procedure? Tankyu and sorry if the english is not correct.
Subject: USB webcams in VirtualPC Date: 1/21/04, 14:20 From: Nick King (email@example.com) Sorry to trouble you. I just read your report on using the Meade LPI in VirtualPC. Great report! My question is simple I suppose. Have you had any other webcams running under VirtualPC? I tried it with my ToUcam with no luck, but then I'm not sure if there's something clever I should be doing. From your report, it seems that you're just using the standard drivers for the LPI that come with it for the PC. Any guidance would be appreciated thanks I'm running a 15" 1.25Ghz Powerbook with 1Gb RAM, VirtualPC 6.1 with Windows 2000Pro as the guest OS (512MB RAM allocated to the guest Machine). Cheers Nick King firstname.lastname@example.org http://www.synner.co.uk ________________ 51º 34' 23" N 00º 21' 04" WMike here: I've only tried the LPI. But I would suspect that if you install the proper driver any USB webcam should in the VPC/W2K environment. You do need to configure VPC to use the USB though as I indicate in my Autostar Suite article.
Thanks for taking the time to reply. That's what I thought. I have installed the relevant drivers for the ToUcam in Windows and enabled the guest machine to use the webcam in the USB settings, but no luck. Never mind, I'll keep at it. Cheers Nick
Subject: picture of Saturn Date: 1/10/04, 12:01 From: Dave Adriance (email@example.com) This is my first attempt at imaging Saturn, and I'm pretty pleased with the results! Image was taken this evening here in Nairobi, Kenya with a TouCam Pro web cam through an ETX-125 using K3CCD Tools. Using the latter's "planetary wizard" function, I stacked 200 of the best frames and then applied unsharp masking with Photoshop. Best regards, Dave Adriance
Subject: Jupiter Date: 1/8/04, 19:57 From: Alan Leutloff (firstname.lastname@example.org) ok here's one more for the record book. This pic of Jupiter taken last night at 3 am (too much coffee that night). Taken with a Phillips Toucam Pro at 60 fr/sec...600 out of 800 images chosen (I used Videodub to edit) then processed with Registax. Final image enhanced using Microsoft Picture It. Used my ETX 125 and a barlow lens w/ the Toucam. Have a great week. Alan
Subject: Images of Jupiter for Planetary Astrophotography Section Date: 1/8/04, 09:40 From: Howard Visser (email@example.com) Attached is a composite of images I took of Callistos shadow and the GRS traversing Jupiters disk on Jan 4th. The images were taken with my ETX90EC, 2X Barlow and a Logitech Quickcam Pro 4000. Each image file was taken at 1/5 sec per frame at 5 frames per second for 30 seconds yielding a 150 frame avi file. The avi files were processed with RegiStax with some subtle wavelet and saturation adjustments to help bring out some of the detail. It was -25 degrees Celsius on Sunday morning so being able to control and focus the scope from the warmth of my kitchen using Steve Hutsons ScopeDriver was a real bonus. After 4 hours of flawless performance by the scope, web camera and software I finally had to call it quits and go get some much needed sleep! Enjoy. Howard
